A6 Pressure Release Valve

A6 Pressure Release Valve

Black / ORANGE SPOT - 3.25 PSI
£20.00
Skip to product information
A6 Pressure Release Valve
1/2
  • A6 Pressure Release Valve
  • A6 Pressure Release Valve
A6 Pressure Release Valve

A6 Pressure Release Valve

H9010050
£20.00

The A6 Pressure Relief Valve has become a firm favourite with many manufacturers of leisure life rafts, RIBs and river rafts around the world.  It is ideal for any use where compact and reliable valves are critical, for example, on commercial & military inflatable boats. The opening and closing pressures are accurately pre-set and repeatable.

A filter cap is available for use in environments where contamination is possible e.g. river rafts. This prevents contamination without affecting the pressure relief function.

A range of pressure settings are available. The valves are marked with the date and pressure setting.

We predominately only have the black and grey 3.25PSI orange spot PRV valves available for immediate dispatch. Please contact sales@henshaw.co.uk to find out the lead times on all other PRV valves.
ColourBlack
Working Pressure
Technical Specs
  • The valve needs minimum maintenance.
  • It should be kept clean using household detergent solution
  • Solvents should not be used on the valves for cleaning.
  • For long term storage they should be kept away from dirt and solvents.
  • Length of storage before installation should not exceed 5 years.
  • Very smooth low profile
  • Rugged and reliable
  • Materials used have high UV resistance
  • Protects from over inflation and excess pressure build-up due to solar heat
  • 100% tested for opening and closing pressures
  • High flow for size
  • Approved to ISO 9650 and ISO 15738 as a transfer valve
  • Rapid installation with clamp fitting – no welding or adhesive required
  • –30ºC to +65 ºC operating temperature
  • Easy removal if necessary, for cleaning
Additional Information
  • We will always endeavour to dispatch your order within 24hours of your order being placed. If this is not possible for any reason a member of the Sales Team will be in touch.
  • We can offer a refund to customers if notified within 14 days of goods receipt. A further 14 days will then be given to customers to return the goods. Goods must be in a resaleable condition, no damage, or defects to receive a full refund.
  • Prices stated are pre standard VAT.
